OEM & V Series
| OEM SERIES | |||
| Designed as component style meters, the
OEM series are ideally suited to both Medium & high volume
applications. Typical uses for this series include personal
instrumentation, integral sensor indicators and power supply monitoring. The range consists of two LCD meters, a bare PCB style meter & metal framed version and a potted LED meter. The LED meter is dimensionally compatible with the metal framed LCD version and has the same digit height. The LED meter is supplied with a red filter as standard. In addition, Lascar are able to provide a custom design service for the family modules. If you require different configurations to the standard of modules shown, please contact our sales team to discuss your specific requirements (subject to minimum order quantity). |
|||
 DC Voltmeter
• 3½ digit LCD • 8mm (0.31”) digit height • 150μA @ 7.5 to 14VDC operation • Auto-zero, auto-polarity • Selectable decimal points • 200mV full scale reading • DIL connection |
 DC Voltmeter
• 3½ digit LED • 8mm (0.31”) digit height • 50mA (typ.) @ 4.75 to 5.25VDC operation • Auto-zero, auto-polarity • Selectable decimal points • 200mV full scale reading • DIL connection |
||
| V SERIES | |||
A series of digital panel meters intended for use in high volume applications. Each meter has good performance, Is easy to use and offers value for money. The V 1, V 125 and V 600 modules are only available in packs of 10. All modules are supplied with bezels. An evaluation pack V EVAL, containing one of each meter and a demonstration unit is also available. |
|||
 DC Voltmeter
• 3½ digit LCD voltmeter • 6.3mm (0.25”) digit height • Auto-zero, auto-polarity • User selectable decimal points • 200mV full scale reading • DIL connection • Bezel 38x18mm • Cut-out 31x15mm |
 DC Voltmeter
• 3½ digit LCD voltmeter • 12.5mm (0.5”) digit height • Auto-zero, auto-polarity • User selectable decimal points • 200mV full scale reading • SIL connection • Bezel 50x24.4mm • Cut-out 41.5x21.4mm |
||
